Features

Galvin Specialised AS/NZS 3718 approved Ezy-Drink® Lead Safe™  Vertical Push Button Drinking Bubbler is ideal for use in playgrounds, schoolyards and public area drinking troughs. Robust and reliable, our Ezy-Drink® Lead Safe™ Vertical Push Button Drinking Bubbler is water conserving and cost-effective.

Features

  • Manufactured using high quality DZR solid brass with less than 0.25% lead content*
  • A unique rubber mouthguard has been specially designed to protect teeth in the rough and tough environment of the schoolyard and playground
  • The mouthguard is made from a nitrile compound which is AS 4020 approved and has a high resistance to fungal and bacterial attack
  • The rubber compound used has a high degree of saturation to ensure the unit has a greater resistance to sunlight and environmental ageing and therefore a long life in the field
  • Vandal resistant design
  • Inbuilt adjustment for consistency of water flow
  • Easy to use self-closing mechanism
  • High quality chrome finish for easy cleaning, added durability and hygiene maintenance
  • Designed and manufactured in Australia, therefore, spare parts and support are available locally, reducing costs of downtime on maintenance
  • Chrome Plated Brass option available TD00P-RM

Technical Information

  • Inlet: 1/2" BSP - Male
  • Outlet: Rubber Mouthguard
  • Headwork: Push Button
  • Working Pressure Range (kPa): 50 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 60 Max
  • Nominal Flow Rate (LPM): 1.7
  • Construction: Lead Safe™ DZR Brass*
  • Finish: Chrome

Click here for more details about Lead Safe™ >
