Specification Data Sheet

The Galvin Ezy-Wash® Pot Filler Attachment helps increase the utility of your pre-rinse unit. This add on pot filler is 305mm long and easily installs into a pre-rinse tap for convenient, versatile use that helps quickly and easily fill stock pots and kettles.

Features

  • Comes standard with hot identification button
  • High quality chrome finish for easy cleaning and hygiene maintenance
  • Recommend installation of pot filler attachments are conducted by a qualified plumber.
  • Australian Made; therefore, spare parts and support are available locally, reducing costs of down time on maintenance

Technical Information

  • WaterMark: AS/NZS 3718 Lic. WMKA0034
  • Inlet: G ¾” - Female
  • Outlet" Aerator
  • Headwork: Jumper Valve
  • Working Pressure Range (kPa): Min 50 - Max 500
  • Working Temperature (°C): Min 5 - Max 65
  • Construction: Lead Safe™  DR Brass
  • Finish: Chrome

Superseding Products

  • TF15-J Ezy-Wash® CP Pot Filler Attachment Type 150 J/V 305mm Reach

This product is compatible with

  • 181.01.56.03 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Single Lever Mixer Pre-Rinse Unit Type 150 Flex Tail - Pot Filler
  • 181.01.56.00 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Single Lever Mixer Pre-Rinse Unit Type 150 Flex Tail - Standard

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
