Specification Data Sheet

Our robust Ezy-Wash® Pre-Rinse food service range is built to comply with all relevant standards and designed for heavy-duty performance across all types of commercial kitchens. Unlike standard kitchen outlets, the high-performance spray valve delivers the right combination of water flow and pressure to effectively loosen debris from pots, pans, and stock pots, making cleaning faster and more efficient.

Features

  • Easy one hand operation
  • Comfortable finger grip handle

Technical Information

  • WaterMark: AS 3718 Lic. WMKA0034
  • Inlet: ½” BSP – Male
  • Outlet: Trigger Spray
  • Working Pressure Range (kPa): 100 - 400
  • Maximum Working Temperature (°C): 5 Min - 65 Max
  • Nominal Flow Rate (LPM): 4.3
  • Construction: Lead Free Brass
  • Finish: Chrome

Superseding Products

  • 37421 Ezy-Wash® Heavy Duty Pre-Rinse Hand Trigger Spray

This product is compatible with

  • 181.01.56.03 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Single Lever Mixer Pre-Rinse Unit Type 150 Flex Tail - Pot Filler
  • 181.01.56.00 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Single Lever Mixer Pre-Rinse Unit Type 150 Flex Tail - Standard
  • 181.00.33.03 Ezy-Wash CP-BS Lead Safe™ Hob Mtd Exposed Mixing Pre-Rinse Unit Type 83 MI Inlet - Pot Filler
  • 181.00.33.00 Ezy-Wash CP-BS Lead Safe™ Hob Mtd Exposed Mixing Pre-Rinse Unit Type 83 MI Inlet - Standard
  • 181.00.32.00 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Concealed Mixing Pre-Rinse Unit Type 82 Basin Tap - Standard
  • 181.03.35.03 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Twin Mixer Pre-Rinse Unit Type 100 Flex Tail - Pot Filler
  • 181.03.35.00 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Twin Mixer Pre-Rinse Unit Type 100 Flex Tail - Standard
  • 181.03.34.09 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Twin Mixer Pre-Rinse Unit Type 84 Flex Tail - Pot Filler (Compact)
  • 181.14.38.03 Ezy-Wash® CP-BS Lead Safe™ Powersoak Pre-Rinse Unit - Pot Filler
  • 181.14.38.00 Ezy-Wash® CP-BS Lead Safe™ Powersoak Pre-Rinse Unit - Standard
  • 181.10.37.03 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd Concealed Mixing Pre-Rinse Unit Type 82 Wall Tap - Pot Filler
  • 181.10.37.04 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd Concealed Mixing Pre-Rinse Unit Type 82 Wall Tap - Pot Filler (250mm)
  • 181.10.37.00 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd Concealed Mixing Pre-Rinse Unit Type 82 Wall Tap - Standard
  • 181.10.38.03 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd Exposed Mixing Pre-Rinse Unit Type 83 FI - Pot Filler
  • 181.10.38.00 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd Exposed Mixing Pre-Rinse Unit Type 83 FI - Standard
  • 181.17.05.03 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd No Stop Pre-Rinse Unit Type 80 FI Inlet - Pot Filler
  • 181.17.05.04 Ezy-Wash® CP-BS Lead Safe™ Wall Mtd No Stop Pre-Rinse Unit Type 80 FI Inlet - Pot Filler (250mm)

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
