Designed and manufactured in Australia, the GalvinCare® Safe-Connect Shower Head promotes a normalised and dignified showering experience in mental health and high-care environments. This innovative unit combines two functions in one fitting, a fixed shower head and an auto-divert detachable hose, allowing both independent and assisted showering without the need for a separate outlet or in-wall diverter.

The patented click-connect design eliminates the hose connection when not in use, reducing ligature risk and improving patient safety. Care staff can fully detach the hose and handpiece after assisted use, lowering the potential for self-harm while maintaining a safe, therapeutic environment.

The unique patented diverter not only enhances safety but also reduces installation costs by more than $500* per unit compared with traditional shower and diverter combinations - lowering plumbing and waterproofing requirements while speeding up installation.

When paired with the CliniMix® Lead Safe™ Ligature Resistant Thermostatic Progressive Shower Mixer and GalvinCare® Handle, the Safe-Connect creates a cohesive, aesthetically normalised shower set, supporting design intent for calm, non-institutional spaces.

Protected under Australian Patent 2017100421 (international patents pending), the Safe-Connect represents a proprietary GalvinCare® innovation - combining superior safety, reduced whole-of-life cost, and streamlined installation.


Features

  • Australian-made and patented (AU 2017100421)
  • Auto-divert technology combines fixed and handheld functions in one fitting
  • Click-connect hose system eliminates hose connection when not in use
  • Reduces ligature and self-harm risk through fully removable hose design
  • Saves more than $500 per unit in plumbing and installation costs
  • Simplifies waterproofing, installation and maintenance
  • Complements CliniMix® Lead Safe™ shower mixers for a normalised appearance

Performance

  • Dual function operation with automatic water diversion
  • Durable, vandal- and ligature-resistant construction
  • Designed for high use healthcare, custodial and mental health facilities

Applications
Ideal for mental health, correctional, and assisted living environments seeking safe, efficient, and aesthetically normalised showering solutions.


Technical Information

  • WELS: 5 Star Rating (5.5L/min)
  • Nominal Flow Rate (LPM): 5.3
  • WaterMark: AS/NZS 3662 Lic. WMK26191
  • Inlet: G ½ - Female
  • Outlet: Shower Rose
  • Headwork: Safe-Connect Shower
  • Working Pressure Range (kPa): 150 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 65 Max
  • Construction: Lead Free DZR Brass
  • Finish: Chrome

*Savings based on estimated general plumbing, waterproofing and installation costs from Queensland in 2025.

Optional Extras

  • 121.92.16.34 GalvinCare® Lead Safe™ MH Detachable Hand Shower for Safe-Connect Shower Head
  • 121.91.16.00 GalvinCare® CP-BS Lead Safe™ MH Detachable Hose Connector for Safe-Connect Shower Head

Spare Parts

  • 121.94.06.09 GalvinCare® BS Lead Safe™ Replacement Cartridge for Safe-Connect Shower Head - 2nd Gen
  • 121.91.16.00 GalvinCare® CP-BS Lead Safe™ MH Detachable Hose Connector for Safe-Connect Shower Head

Alternative Product Options

  • 121.36.64.91 GalvinCare® CP-BS Lead Safe™ MH Ligature Resistant Safe-Connect Shower Head & Connector
  • 121.36.64.92 GalvinCare® CP-BS Lead Safe™ MH Ligature Resistant Safe-Connect Shower Head & Hand Shower

Superseding Products

  • 42013 GalvinCare® CP-BS Mental Health Ligature Resistant Safe-Connect Shower Head

This product is compatible with

  • 121.92.16.34 GalvinCare® Lead Safe™ MH Detachable Hand Shower for Safe-Connect Shower Head

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.

Galvin Engineering offers a range of ligature resistant, anti-ligature, vandal resistant, and anti-vandal products designed to reduce the risk of self-harm, suicide, or vandalism, but we cannot offer any guarantee that these events will not take place. Therefore, it is important to understand that installation of these products will not eliminate all risks.

When we use the terms ligature resistant and/or anti-ligature about our products, it means that we have designed and tested these products to reduce the risk of that product being used as a ligature attachment point. They will not protect or prevent injury when the risks were unknown to us at the time of the design of the products. They are not a replacement for professionals who are trained in the proper evaluation, management, and supervision of persons at risk of self-harm or suicide.

When we use the terms vandal resistant and/or anti-vandal about our products, it means that we have designed and tested these products to reduce the risk of that product being vandalised. They will not protect or prevent damage when the risks were unknown to us at the time of the design of the products.

Galvin Engineering recommends that designers, installers, facility managers, and anyone intending to rely on or use any products displayed in our literature or on our website, satisfy themselves about the suitability of the products for their intended use in the building design, and ensure they are being installed, used, and maintained in accordance with our instructions. Facility managers, clinicians, and carers need to ensure that reasonable steps are taken to reduce the accessibility of unnecessary ligatures to at-risk patients, confirm that adequate risk mitigation controls are in place, and make sure that applicable health, safety and patient care standards are being met.

Galvin Engineering makes no express or implied warranties regarding the ability of the product to prevent death or injury, to resist all ligature attachment, or to prevent vandalism. No responsibility is assumed by Galvin Engineering for any incidental or consequential damages resulting from the use of any products sold by Galvin Engineering. To the fullest extent permitted by law, Galvin Engineering excludes all liability for damage or injury to any person, damage to any property, and any indirect consequential claims, loss or damage.
