Designed to promote a normalised environment our innovative Australian Made GalvinCare® Mental Health Anti-Ligature Safe-Connect Shower Head offers an auto-divert detachable hose, providing two functions in one single fitting. This allows for the shower to be used for unassisted or assisted showering without the need to install two separate outlets and an in-wall diverter.

Minimising risk due to its anti-ligature and anti-vandal design, the fixed shower head can be safely used by patients independently. The inbuilt automatic diverter enables for a detachable hose to easily be connected, allowing carers to safely provide assisted showering and removing the hose from the room when not in use.

Patented in Australia (2018202412), New Zealand (741366) and Singapore (10201802953U); other international patents pending.

  • AS/NZS 3718 approved
  • Anti-ligature and anti-vandal design
  • Enables assisted and unassisted showering thanks to its detachable handheld shower
  • Saves on labour and maintenance as it replaces multiple fixtures (shower head, diverter, handheld shower, wall connector and adaptor)
  • High quality chrome finish for easy cleaning, added durability and hygiene maintenance
  • Suitable for new builds or retrofit
  • Designed and manufactured in Australia, therefore, spare parts and support are available locally, reducing costs of downtime on maintenance


Technical Information

  • WELS: 5 Star Rating (6.0L/min)
  • Nominal Flow Rate (LPM): 5.3 - 5.8
  • WaterMark: AS/NZS 3662 Lic. WMK26191
  • Inlet: 1/2" BSP - Female
  • Outlet: Shower Head
  • Working Pressure Range (kPa): 150 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 70 Max
  • Construction: Brass
  • Finish: Chrome

Spare Parts

  • 121.94.06.09 GalvinCare® BS Lead Safe™ Replacement Cartridge for Safe-Connect Shower Head - 2nd Gen
  • 121.91.16.00 GalvinCare® CP-BS Lead Safe™ Mental Health Detachable Hose Connector for Safe-Connect Shower Head

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

In the absence of a legal or industry definition of anti-ligature or ligature resistant products, when we use these terms, we are referring to products that are designed and manufactured with the intention of reducing the risk of ligature attachment to the product(s). Galvin Engineering Pty Ltd will always endeavour to design and test our anti-ligature product(s) to reduce the risk of product ligature attachment that may result in serious injury or death. Whilst all reasonable measures are taken at the time of design, the anti-ligature design of the products are not intended to and will not:
a. Replace protective measures that need to be taken in the specific circumstances of usage;
b. Substitute the need for supervision of those who may be at risk;
c. Protect and or prevent those at risk against any self-harm instances that may occur when installed; and
d. Protect and or prevent injury when the risks where unknown to us at the time of the design of the product(s).
Galvin Engineering Pty Ltd does not offer and does not represent or warrant that any product(s) for sale are ligature-free. Therefore, Galvin Engineering will not be liable for any claims, loss, or damages arising from ligature attachment on our products. It is the purchaser's responsibility to ensure that products purchased and installed are suitable for the environments in which they are installed, and suitable supervision and protective measures are in place to protect those at risk.
